    Solid Rod and Toroid Tester

    H21 Series
    Test pieces in round or square rod forms can be very easily tested for their DC properties. Properties such as coersivity, permeability, magnetization can be tested. The field for testing can be taken to 600A/cm. With our newly designed fixture, it can be taken up to 1000A/cm.

    Solid Rod and Toroid Tester
    Dimensions: 8mm, 10mm, 12mm diameter and 10mm x 10mm square shape rods, strips
    Frequency of Testing: DC
    Max. Field: 1000 A/cm
    Lease Count of Field Measurement:: 0.001 A/cm
    Max Flux Density: 3T
    Properties Tested: Watt Loss, Permeability, Saturation Flux Density, Remanence, Coersivity, Hrms, Brms
    Accuracy: 1%
    Wide Material Type Testing—cobalt steel, pure iron, low carbon, magnetic steel, cobalt alloys etc.
    ASTM/ IEC /IS Standard Compliance
    Measurement accuracy—1%
    BH Loop Graphical Display
    Calibration Traceable to International Standards
    Variety of Magnetic Properties tested
    Fully computerized system, Very Low Measurement Time,
    Data Automatically Generated and Saved.
    No Operator Skill Required, Easy Installation and Operation.
    All accessories Supplied for Smooth Running.
    Detailed Test Reports for Design Applications.
    Summery Test Reports for Customer Submission
