    Single Sheet Tester

    S15 Series
    Incoming material inspection can be very useful where strict quality standards are maintained. It saves a lot of processing cost since lossy material is inspected at the entry level before it goes to production level. Epstein Stack testing is one of the oldest and widely used method for electrical sheet testing.
    Similar to Epstein stack testing, this method uses less material. Ferrites India Make Single Sheet Tester adhere to ASTM standards and provide accurate results.

    Single Sheet Tester
    Standard: IEC 60404-2, IEC 60404-10
    Dimensions: 300mm x 30mm
    Frequency of Testing:DC– 1 kHz
    Max. Field: 100 A/cm
    Max Flux Density: 3T
    Properties Tested: Watt Loss, Permeability, Saturation Flux Density, Remanence, Coersivity, Hrms, Brms
    Accuracy: 1%
    Wide Material Type Testing—CRGO, CRNO, Nano Crystalline, Amorphous etc.
    Measurement accuracy—1%
    Acceptable Sample Thickness as Low as 0.1mm.
    BH Loop Graphical Display
    Calibration Traceable to NABL Accredited Lab.
    No Hidden Cost
    Fully computerized system, Very Low Measurement Time,
    Data Automatically Generated and Saved.
    No Operator Skill Required, Easy Installation and Operation.
    All accessories Supplied for Smooth Running.
    Detailed Test Reports for Design Applications.
    Summery Test Reports for Customer Submission
