    Epstein Tester

    S21 and S21R Series
    Incoming material inspection can be very useful where strict quality standards are maintained. It saves a lot of processing cost since lossy material is inspected at the entry level before it goes to production level. Epstein Stack testing is one of the oldest and widely used methods for electrical sheet testing.

    Epstein tester
    Standard: IEC 60404-2
    Dimensions: 300mm x 30mm, Acceptable Sample Thickness as Low as 0.1mm.
    Frequency of Testing: DC– 1 kHz
    Max. Field: 100 A/cm
    Max Flux Density: 3T
    Properties Tested: Watt Loss, Permeability, Saturation Flux Density, Remanence, Coersivity, Hrms, Brms
    Accuracy: 1%
    Wide Material Type Testing—CRGO, CRNO, Nano Crystalline, Amorphous etc.
    ASTM/ IEC /IS Standard Compliance
    BH Loop Graphical Display
    Calibration Traceable to NABL Accredited Lab.
    Fully computerized system, Very Low Measurement Time,
    Data Automatically Generated and Saved.
    No Operator Skill Required, Easy Installation and Operation.
    All accessories Supplied for Smooth Running.
    Detailed Test Reports for Design Applications and Summery Test Reports for Customer Submission.
